Overview
HS sand wash plant adopts integrated dual-cyclone separation and vibrating dewatering screening technology. It combines sand-water separation and fine sand classification, recovery into a single unit. During operation, the HS sand wash plant quickly achieves coarse sand dewatering, fine sand recovery and wastewater purification. It delivers a capacity of 100–120 m³/h, with 30% less energy costs.
HS sand wash plant could process complex slurries such as construction mud and tailings wastewater to produce 2 grade of quality products.
HS Sand Wash Plant Applicable Scenarios:
- Aggregate Processing
- Comprehensive Tailings Treatment
- Construction Waste Resource Recycling
- Concrete Batching Plants Wastewater Recycling
- River Dredging For Hydraulic Engineering
-
Working principle
Core Technology
Breaking through traditional single-recovery models, HS sand wash plant innovatively integrates dual-cyclone separation and vibrating dewatering screening technologies. The equipment features a scientifically optimized layout, delivering high-efficiency, stable, and reliable operation.
Structurally, HS sand wash plant consists of 4 core modules: feeding circulation system, dual-cyclone separation module, dual dewatering screening unit, structural support unit, forming a fully integrated processing system.
-
Features & Benefits
1. Multi-stage collaborative separation. Minimizes loss of high-quality sand and efficiently produces finished-grade sand.
2.Suitable for diverse operating scenarios, ensures continuous, stable operation with high reliability.
3. Rational structure with small footprint, simplified installation and maintenance.
4. Streamlined access to critical parts, reducing O&M difficulty and costs.
5. Optimized wear-part design, enhanced durability for extended service life.
6. Customizable configurations, tailor-made models available per client requirements.
-
Specifications
Model Capacity(t/h) Water Volume(m³/h) Cyclone 1(mm) yclone 2(mm) Dewatering Screen(mm) Power(kw) HS100 ≤100 300 610 350 ZKX1848 74 HS150 ≤150 400 660 400 >ZKX2448 >93.5 HS200 ≤200 500 710 500 >ZKX3060 >114 HS250 ≤250 700 840 610 >ZKX3660 >157 HS300 ≤300 800 900 660 >ZKX4272 >190 -
